Mixing Machine

Your Professional Mixing Machine Manufacturer!

Founded in 1998, Covering an area of 15000 square meters, Suntech Machinery(Xinxiang) Co.,Ltd is located in Xinxiang City, Henan Province, which is the production base of the vibration related equipment, we are specialized in providing solutions on powder granules processing which including sieving, conveying and mixing, being in this field for over 20 Years.

Why Choose Us

01/

Our produck
Our produck have Vibrating Screen, Screw Conveyor, Belt Conveyor, Vacuum Conveyor, Bag Dumping Station. The product application in Food, Chemical, Pharmaceutical, Mineral, Pottery, Metallurgy.

02/

Quality Management
We are qualified with ISO quality management system and CE certificate, all the main components are fine manufactured in our own factory with strict inspection, and quality is always our priority.

03/

Advanced Equipment
We have Laser Cutting Machine, CNC bending machine, Spot Welding Machine, Polishing Machine,Fixed bench press, air plasma cutting machine, platform CNC punch, CNC hydraulic guillotine shear, four-column hydraulic press, universal lifting table milling machine, radial drilling machine, hydraulic digital display sheet Bending machine,

04/

Production Market
Our products have been exported to Russia, USA, France, Namibia, Saudi Arabia, Thailand, Uruguay, Singapore, Spanish, Germany, Cyprus,Botswana, Korea, Switzerland,Newzeland, Pakistan, Brazil, Malaysia, Spanish, Peru, Chile,Turkey, Portugal, etc.

Main Parameters

Type	Material barrel volume (L)	Max loading volume (L)	Max loading weight (kg)	Spindle rotation speed (r/min)	Motor power (kw)	Overall dimensions (mm)	Weight (kg)
SYH-5	5	4	5	24	0.37	60010001000	150
SYH-100	100	80	80	15	2.2	120018001500	500
SYH-200	200	150	150	12	3	130016001500	750
SYH-400	400	300	200	10	4	150022001500	1200
SYH-600	600	450	300	10	5.5	185025001650	1500
SYH-800	800	600	400	10	7.5	190024002100	1650
SYH-1000	1000	750	500	10	11	195025002400	1800
SYH-1500	1500	1200	750	10	18.5	260025002350	250

Advantages of Mixing Machine

Uniform Mixing for Consistency

One of the biggest advantages of a mixing machine is its ability to produce homogeneous mixtures, ensuring that every batch maintains the same standard. Whether you’re blending powders, liquids, or viscous materials, uniformity is key to quality.

Better Control Over Ingredients

Advanced industrial mixing machines allow precise control over the mixing speed, duration, and temperature—key factors in preserving the chemical and physical properties of your product.

Improved Texture and Stability

Products like creams, gels, and sauces require a smooth, lump-free texture. A well-designed mixing system ensures emulsification and particle distribution, enhancing product aesthetics and usability.

Reduced Human Error

Manual mixing is prone to inconsistencies. Automated mixing equipment reduces variability, enhances accuracy, and lowers the risk of contamination—resulting in superior product quality.

Application of Mixing Machine

Adhesives and Sealants
The adhesives and sealants industry relies heavily on effective mixing and blending technologies to ensure proper homogenization of miscible fluids and uniform dispersion of high-viscosity, often dissimilar, materials.

Batteries and Electronics
In the battery and electronics manufacturing sector, mixing machine play a vital role in producing advanced materials such as aluminum oxide suspensions, silicone gels, conductive pastes, battery slurries, and highly viscous inks.

Medical Cannabis
In medical cannabis production, mixing machines are essential for emulsifying, dispersing, and blending cannabinoid extracts such as CBD oil, THC distillates, hash oil, and other bioactive components.

Cosmetics
The cosmetics and personal care industry depends on precision mixing solutions to produce sensitive, high-quality products such as lotions, creams, serums, gels, and hair care products. The mixing machine ensures homogeneous emulsification, efficient powder wetting and controlled particle size reduction.

Food Industry
The food and beverage industry relies extensively on hygienic mixing machine for all stages of production, as precise mixing is fundamental to achieving desirable taste, mouthfeel, nutritional value, and product safety in food products.

Plastics and Composites
The plastics and composites industry depends on high-performance mixing solutions for compounding, blending, and dispersing polymers, additives, fibers, and colorants. The production of engineering plastics, polyamides, resins, plastisols, thermosets, thermoplastics, and composite injection molding formulations requires precise melting, dispersing, and homogenization of raw materials.

Inks, Paints, and Coatings
The production of inks, paints, and coatings is among the most technically demanding mixing and dispersing applications across all industries. Achieving the correct pigment dispersion, viscosity, and color uniformity requires precision mixing using equipment such as high-speed dispersers, shear mixers, sand mills, bead mills, and multi-shaft mixers.

Chemical Industry
The chemical industry relies on a broad range of industrial mixing solutions for production processes involving high to low viscosity mixing, dry blending, particle size reduction, emulsification, homogenization, and powder dispersion.

Components of Mixing Machine

Horizontal Ribbon Mixer

A ribbon mixer, also known as a ribbon blender, uses two intertwined metal strips, similar in shape to a double helix, to move material from one side of the mixer to another. As the material passes in each direction, it mixes together.

Planetary Mixer

A planetary mixer is typically used for mixing dough or batters in bakery operations. It has a central rotating attachment (such as a dough hook or whisk) that moves in a circular motion while the bowl remains stationary.

Paddle Mixer

A paddle mixer is similar to a horizontal ribbon mixer, except that the mixing action and gentler. As the paddles move the material through the mixer, it creates a cohesive mix. A paddle mixer provides efficient, gentle blending, but it can also experience weakness in mixing suspensions.

Drum Tumbler Mixer

Drum Tumbler mixer is usually for powders and solids, but in some cases, liquids are also accommodated. The movement of the tumbler rotates the solids up and down. Gravity plays a role in mixing the products and drum baffles aren’t even needed at times to break solids into smaller particles.

Double Cone Mixer

A double cone mixer is designed to mix powders and granules. The unique design of two cones rotating ensures a uniform and gentle mix, making it ideal for delicate ingredients.

Static Mixers

Static mixers are usually used to mix gases, liquids or liquids and gases together. It may use a series of blockages that force the materials together and break down the substances so they mix, similar to an emulsifier.

Packing & Shipping

For the single machine, or the multiple machine and shipped in LCL, we usually take the plywooden box outside for damage proof and ensure the machine safe.

productcate-1-1

FAQ

Q: How can we get a quotation on right model sieve machine

A: The powder you need to sieve, the mesh size, the target capacity, the ideal machine types etc.

Q: What is the real delivery time of your factory?

A: We have rich spare parts in stock, for the general standard machine, 3-5 working days can complete as per your production order, 7-15 working days for the whole production line machine.

Q: How do you ensure the quality of your machine?

A: Generally, our equipments are the most durable type in the same industry, professional design engineers, skilled workers and strict quality control system can ensure every machine with best working performance.

Q: How do your after-sale service work if the machine break down?

A: The machine is complete sending, no need install again, just need to connect the power source and then can use directly. We will give you video guidance on how to operate. The wearing parts is sent together with the machine, can be replaced after it worn out.

Q: What are the benefits of using mixing machines in food processing?

A: Mixing machines in food processing ensure consistent product quality, improved texture, and enhanced flavor. They optimize mixing processes, reduce manual labor, and increase production efficiency.

Q: How do mixing machines work?

A: Mixing machines combine ingredients into a homogeneous mixture through mechanical agitation. A motor drives an impeller or agitator, creating a complex flow pattern that promotes thorough mixing of components.

Q: What types of mixing machines are used in the pharmaceutical industry?

A: High-shear mixers, tumble blenders, and planetary mixers are commonly used in the pharmaceutical industry. They are designed to achieve uniform distribution of active ingredients and excipients while complying with strict manufacturing guidelines.

Q: Can mixing machines handle high-viscosity materials?

A: Yes, certain mixing machines, such as planetary mixers and high-shear mixers, are designed to handle high-viscosity materials. They feature powerful motors and specialized agitators that can effectively mix viscous substances like pastes and gels.

Q: How do I choose the right mixing machine for my application?

A: When selecting a mixing machine, consider factors such as material properties, desired mixing intensity, batch size, and industry-specific requirements. Consult with a reputable mixing machine manufacturer to determine the best solution for your needs.

Q: What role do agitation techniques play in mixing processes?

A: Agitation techniques influence the quality and consistency of the final product by enhancing dispersion, particle interaction, and reaction rates during mixing.
