Let's learn about the common sense of installation and maintenance of vibration feeders

A vibrating feeder is a device that can uniformly, regularly, and continuously transport large and granular materials from a storage bin to a receiving device. In the sand and gravel production line, it can be continuously and uniformly fed into the crusher and coarse screened materials. Vibration feeders are widely used as crushing and screening equipment in industries such as metallurgy, coal mines, mineral processing, building materials, chemicals, abrasives, etc.





Vibration feeder is a feeding equipment with economic and technical indicators, which has the following characteristics:

1. Small size, light weight, and simple structure;

2. Easy installation and maintenance, low operating costs;

3. High efficiency and large feeding volume;

4. Low power consumption, high power factor;

5. Low noise helps improve the working environment;

6. The equipment operates in a state far from resonance, with stable amplitude, reliable operation, and strong adaptability to various materials;

7. Add ingredients and adjust the eccentric block to continuously adjust the feeding amount.

Let's learn about the installation and maintenance of vibration feeders.

Installation of vibrating feeder:

In a vibrating feeder, it should be installed horizontally to ensure uniform and stable feeding, and to prevent free flow of materials. To continuously feed conventional materials, they can be installed 10 ° downwards. For sticky materials and materials with high moisture content, installation can be done by tilting downwards by 15 °.

2. The installed paper feeder should have a horizontal clearance of 20mm, and the suspension device should be flexible.

Before conducting the air test, all bolts should be tightened once, especially the foundation bolts of the vibration motor, and should be tightened again after continuous operation for 3-5 hours.

During the test run, the two vibration motors must rotate in opposite directions. If any abnormalities are found, the stability of current and noise should be stopped in a timely manner.



5. Lube the lubricating grease for the motor bearings every two months, and lubricate once a month during the high temperature season.

Maintenance requirements for vibration feeder:

During operation, the feeder should always check the amplitude, vibration motor current, and surface temperature of the motor. Require uniform amplitude before and after, without swinging left and right, and stable vibration motor current. If any abnormal situation is found, the machine should be stopped immediately.

The lubrication of the vibration motor bearings is crucial for the normal operation of the entire paper feeder. During use, the bearings should be regularly filled with two types of fluidized 2 # molybdenum lubricating grease, and refilled every two months. Disassemble and repair the motor every six months, and replace the internal bearings.
